KickAss Canopy Power System with 40A DCDC-MPPT Charger - Wired Switching

RRP: Not confirmed at time of listing
Condition: Used

Key Specifications
System Type: Portable canopy-mounted power system with integrated DCDC-MPPT solar charger
Charge Controller: 40A DCDC-MPPT (Maximum Power Point Tracking)
Solar Input: 10-32V
Alternator Input: 9-32V
Charge Output: 40A maximum
Battery Compatibility: KickAss Lithium batteries (CAN port for communication)
USB Outputs: 2 x USB-A QC 3.0 (45W combined) + 2 x USB-C PD (45W combined)
DC Input/Output: 3 x 50A Anderson connectors (combined 50A maximum)
MPPT Input: 1 x unregulated solar
Alternator Input: 1 x 3-pin Anderson
Battery Input/Output: 1 x 175A Anderson
Switched Outputs: 10A, 10A, 15A, 20A, 30A circuits + 50A combined maximum
Control Interface: Digital display with A/B button navigation
Integrated Controls: Power, interior lights, side lights, outlets, speaker functions
Dimensions: Compact rectangular form factor suitable for vehicle canopy mounting
Material: Heavy-duty black powder-coated steel enclosure with hexagonal ventilation pattern

Included
Main power unit with integrated control panel
Digital display module
Wired switching harness and control buttons
All Anderson connectors and terminals as specified
Mounting hardware

Condition Notes
Used unit in functional condition. Surface shows typical wear marks and minor cosmetic scuffing consistent with field use. All electrical connections intact. Control buttons responsive. Ventilation grilles clear. No visible corrosion or water ingress.

This KickAss Canopy Power System is a comprehensive 12V auxiliary power solution designed for vehicle canopy integration, caravan, camper van, and off-road applications. The integrated 40A DCDC-MPPT charger enables simultaneous charging from solar panels and vehicle alternator inputs, with intelligent maximum power point tracking for optimal solar efficiency. Multiple USB outputs support modern device charging, whilst the wired switching system provides dedicated circuits for auxiliary loads including interior and side lighting, outlets, and audio systems. The system is specifically engineered for KickAss lithium battery compatibility via CAN communication protocol, ensuring safe and efficient power management.

Suitable for: 4WD canopy systems, caravan auxiliary power, camper van installations, mobile workstations, and off-grid power applications requiring multi-source charging and distributed load switching.

Pickup only from Acacia Ridge. Please inspect prior to bidding. Sold as described.
